Click on "EXECUTE" button to execute code and goto mimic.
If you want to download code click on "DOWNLOAD" button.
The MIMIC will open on left side of screen.
Mimic
Click on selected output pin terminal(red circle) and click on anode terminal(red circle) for connection of the selected output pin to anode or vice versa.
Click on cathode terminal(red circle) and click on resistor terminal(red circle) for connection of cathode to resister or vice versa.
Click on "Check Connection" button.
If connection is wrong, click on "Reset Connection" button and follow steps 1, 2 and 3.
If connection is successful, click on "Run" Button.
Output LED is on. Observe the square wave graph.
Click on "REFRESH" button to re-executing the experiment.
