Click on "EXECUTE" button to execute code and goto mimic.
If you want to download code click on "DOWNLOAD" button.
The MIMIC will open on left side of screen.
Mimic
Click on selected output pin terminal(blue circle) and click on anode terminal(blue circle) for connection of the selected output pin with anode or vice versa.
Click on cathode terminal(blue circle) and click on resistor terminal(blue circle) for connection of cathode with resister or vice versa.
Click on "Check Connection" button.
If connection is wrong, click on "Reset Connection" button and follow step 1, 2 and 3.
If connection is successful, click on Run Button.
Output LED is on. Observe the square wave graph.
Click on "REFRESH" button to re-executing the experiment.
