Click on "EXECUTE" button to execute code and goto mimic.
If you want to download code click on "DOWNLOAD" button.
The MIMIC will open on left side of screen.
Mimic
Click on selected input channel terminal (blue circle) and click on analog input voltage terminal (blue circle) for connection of the selected input channel with analog input voltage or vice versa.
Click on "Check Connection" button.
If connection is wrong, click on "Reset Connection" button and follow steps 1 and 2.
If connection is successful, click on Run Button.
Now observe the ADC output on Digital Output Display.
Click on "REFRESH" button to re-executing the experiment.
