Instructions:

1. Before starting the process read the instructions completely
2. Press Start button to start the experiment procedure.
3. Select the Type of Operation of your choice.
4. Select the Type of Joint
5. Select the Type of Material
6. Select the Type of Electrode
7. Press Start button to start the start the process of welding.
8. Observe the simulation.
Mouse Controls
• Scroll for Zoom in and Zoom out
• Left click and move mouse to rotate
• Right click and move to move setup
9. Repeat the experiment
