Click on "EXECUTE" button to execute code and goto mimic
If you want to download code click on "DOWNLOAD" button
The MIMIC will open on left side of screen
Mimic
Connect the Output Pin from the Arduino to the transistor by click on the connecting points
Connect the selected Input Pin from the Arduino to the sensor by click on the connecting points
Connect the LED and Output Pin (selected pin) according to the circuit diagram by click on the connecting points
Connect the Output Pin (selected pin) and DC motor according to the circuit diagram by click on the connecting points
Connect the relay and power supply according to the circuit diagram by click on the connecting points
Click on "Check Connection" to validate the circuit connections
If connections are shows wrong then you can click on the particular connected line to delete the wrong connection (wrong connection shows in RED color)
After completion of circuit click on check connection fire will displayed in front of sensor
Click on "Plus" and "Minus" buttons for increase the temperature
When temperature reached in between the sensing range of the sensor then current will flows through the circuit and motor starts running
Observe the changes in circuit and rotation of motor while changing the temperature from sensor
Click on "Next Level" button for next steps
Questions
Read all the questions carefully and submit the answer
