Beam and slab formwork using flex system
Objective:
To Set the Beam and Slab using Flex System.
Apparatus Materials:Tripod Stand, CT prop, fourway head, Aluminium Beam, Timber Beam, Plywood Sheathing, Beam Forming support.
Step 1
Calculation of cross-sectional area:
Welcome to
Foundation in Beam Formwork Experiment
of Formwork Technology in Civil Engineering Virtual
Lab
developed by Prof. K. N. Jha, Department of Civil
Engineering, IIT Delhi.
Prof. K. N. Jha
IIT Delhi
| Calculations: | |
|---|---|
| Total Length(m) | |
| Weight(kg) | |
| Cross-sectional area (mm2) | |
Results
Date of test:
Grade of Steel: 550 SD steel
| Weight of specimen (g) | 698 |
|---|---|
| Length of specimen (mm) | 805 |
Effective cross-sectional area,
So(mm2) =
|
110.4 |
Original gauge length L (mm) =
|
59.4 |
| Choosen gauge length Lo (mm) | 60 |
| Yield Stress (MPa) | 480.84 |
| Tensile Strength (MPa) | 600.62 |
| TS/YS Ratio | 1.25 |
| Final gauge length, Lu mm | 77 |
| Final diameter minimum (mm) | 7.1 |
| % Elongation after fracture | 28.33 |
| % Reduction in area | 64.13 |
